Haier HW100-B14959U1 User Manual

11.1 Preparation
▶ Take the appliance out of the packaging.
▶
keep them out of childrens reach. While opening the package, water drops may be
seen on plastic bag and porthole. This normal phenomenon results from water tests
in the factory.
Note: Packaging disposal
Keep all packaging materials out of children´s reach and dispose them in an environmen-
tally friendly manner.
11.2 OPTIONAL: Install noise reduction pads
11-2
11-3
11-1
1.When opening the shrink package,you will find four
noise reduction pads.These are used for reducing
noise(Fig. 11-1).
(Fig. 11-2).
(Fig. 11-3).
-trop ,edis sti ot nwod enihcam gnihsaw eht yaL .2
hole pointing upwards, bottom side towards op-
3. Take out the noise reduction pads and remove the
double-sided adhesive protective film; paste around
the bottom; the noise reduction pads under the w-
ashing machine cabinet as shown in Figure 3(two
longer pads in position 1 and 3, two shorter pads in
position 2 and 4). Finally set the machine upright again
29
11-Installation
EN
Warm tip:
Noise reduction pad is optional , could help to reduce
noise , please assemble it or not according to your
own demand.

Haier HW100-B14959U1 Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Drum volume	63 L
Control type	Rotary, Touch
Display type	LED
Door opening	Side opening
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	10 kg
Apps supported	hOn
Cycle time (max)	238 min
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	70 dB
Noise level (wash)	- dB
Number of washing programs	-
Power plug type	Type G
AC input voltage	220 - 240 V
Energy efficiency scale	A to G
Water consumption per cycle	51 L
Package depth	636 mm
Package width	650 mm
Package height	890 mm
Package weight	68000 g
Repairability index	8

Weight and Dimensions

Depth	570 mm
Width	600 mm
Height	850 mm
Weight	65000 g
