Haier HW100-B14959U1 User Manual

12-Technical data
EN
33
HW100 HW90 HW80
Voltage in V 220-240 V~/50Hz
Current in A 10
Max power in W 2000
Water pressure in MPa 0.03≤P ≤1
Netto weight in kg 65
12.1 Additional technical data
12.3 Standards and Directives
This product meets the requirements of all applicable EC directives with the correspon-
ding harmonised standards, which provide for CE marking.
Note: The exact height of your washer is dependent on how far the feet are extended from
the base of the machine. The space where you install your washer needs to be at least
40mm wider and 20mm deeper than its dimensions.
TOP VIEWL LAWFRONT VIEW
A
B
F
E
C D
HW100 HW90 HW80PRODUCT DIMENSIONS
B Overall width of product mm
A Overall height of product mm
C Overall depth of product
Overall depth of product mm
(To main control board size) mm
D
Depth of door open mmE
F
Minimum door clearance
to adjacent wall mm
12.2 Product dimensions
850
595
497
577
1085
00 3

Haier HW100-B14959U1 Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Drum volume	63 L
Control type	Rotary, Touch
Display type	LED
Door opening	Side opening
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Drum capacity	10 kg
Apps supported	hOn
Cycle time (max)	238 min
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	70 dB
Noise level (wash)	- dB
Number of washing programs	-
Power plug type	Type G
AC input voltage	220 - 240 V
Energy efficiency scale	A to G
Water consumption per cycle	51 L
Package depth	636 mm
Package width	650 mm
Package height	890 mm
Package weight	68000 g
Repairability index	8

Weight and Dimensions

Depth	570 mm
Width	600 mm
Height	850 mm
Weight	65000 g
