2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.2-3):
Note:
1 Detergent/Softener drawer
2
Control panel
3
Worktop
4 Door
5 Filter cover
6 Adjustable feet
1 Transportation bolts (T1-T4)
2 Backcover
Backcover screws
（7 EA）
3
4 Power cord
5 Water inlet valve
6 Drain hose
2-1 2-2
2-3
2-Product description
Inlet hose
assembly
5 Blanking
plugs+2 screws
Drain hose
bracket
User manual
Warranty card
Warranty card
Bottom plate
Due to technical changes and different models,the illustrations in the following ch-
apters may differ from your model.
7
1
3
2
6
4
5
1
2
3 4 5 6
T1
T2
T3
T4
2x
2x
Noise reduc-
tion pads
(HW120-BP
14959S6)
