Haier HW120-B14876N User Manual

2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig. 2-3):
Note:
-
2-3
I1
R5
R9 R10
R6
R7
R8
1 Detergent /
Softener drawer
2 Work top
3 Programme selector
4 Panel
5 Washer door
6 Service flap
7 Adjustable feet
1 Iron bar (I1 - I2)
2 Transportation bolts (T1-T4)
3 Rear wall reinforcement
(HW80:4pcs R1-R4; HW100/120:10pcs R1-R10)
4 Power cord
5
Water inlet valve
6
Drain hose
7 Rear wall reinforcement screws
2-1
2-2
Inlet hose-
assembly
6 Blanking
plugs
Drain hose
bracket
User manual
Warranty
card
1 2 4 5 6 73
Noise reduc-
tion pads
2x
2x
7
EN
2-Product description
8 Door handle
)HW100/120:2pcs ; scp1:0 8WH(
)HW100/120:2pcs scp1:0 8WH(

Haier HW120-B14876N Specifications

General

Door hinge	Left
Water fill	Cold
Control type	Buttons, Rotary
Display type	LED
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Country of origin	China
Custom panel-ready	-
Appliance placement	Freestanding
Inverter technology	Yes
Drum capacity	12 kg
Wi-Fi controlled	No
Delay start (max)	24 h
Residual moisture	52 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	65 dB
Noise level (wash)	53 dB
Number of washing programs	14
Power plug type	Type G
Water consumption per cycle	56 L
Package depth	752 mm
Package width	684 mm
Package height	962 mm
Package weight	89000 g
Customs product code (TARIC)	8450200000
Quantity per shipping (inner) case	1 pc(s)
Quantity per intermodal container (40ft, HC)	90 pc(s)

Weight and Dimensions

Depth	600 mm
Width	595 mm
Height	850 mm
Weight	80000 g
