16
Care and Maintenance
Transporting the washing machine
If the washing machine is to be transported, the
packing bolts and rubber spacers should be
replaced to prevent damage.
a: Remove the back cover plate, by removing
the 3 screws shown and sliding down the back
cover plate (4 & 5).
b: Remove the plastic plugs fr om the 3 packing
bolt holes (insert - 6).
c: Position all 3 rubber spacers inside the back
of the washing machine (6).
d: Line up the holes and insert all 3 packing
bolts and tighten using a 13mm spanner or large
flatblade screwdriver (6).
e: Replace the back cover plate and refit the
screws.
6
4
5
