6. Operation Instructions
Basal information
6-1 Front panel controls
6.2 Back panel controls
- 23 -
AC INPUT
100-240V~50/60Hz
HDMI 1 HDMI 2
L
R
AV
Pr
Y
Pb
COMPONENT
INPUT
AUDIO
INPUT
HEADPHONE
PC AUDIO
INPUT
RF INPUT
VGA INPUT
COAXIAL
1. SOURCE: Display the input source menu.
2. MENU: Display main MENU.
3. CH+/CH-: In TV mode, press "CH+" or "CH-" to
change the channel up and down. In MENU mode, press
"CH+" or "CH-" to select items in standby mode, press
"CH+" or "CH-" to turn on the TV.
4. VOL+/VOL-: Adjust sound level. In MENU mode,
press "VOL+ " or "VOL- " to adjust the item that you
selected.
5. STANDBY: Press this button to turn the unit ON
from STANDBY mode. Press it again to turn the set
back to STANDBY.
6. USB INPUT
SOURCE
MENU
CH+
CH-
VOL+
VOL-
STANDBY
USB
1
2
3
4
5
6
