Hantek HDG2000B Series User Manual

Basic Operation
HDG2000 Series Arbitrary Waveform Generator 8
1. Menu softkeys F0-F6
2. Function waveform button
3. Channel 1 and Channel 2 Switch Button
4. Function menu
5. Knob and cursor arrows
6. Numeric Keypad
7. Channel 1 and Channel 2 output buttons
8. Trigger button
9. Channel 1 and Channel 2 output Connector
10. Sync Connector
11. Modulation signal Input Connector (for all kinds of External Modulation Signal Source)
12. High frequency Connector(24MHz to 2.7GHz) HDG2000C
13. Low frequency (24MHz or lower)/External trigger Connector
14. Digital channel
15. USB port
16. SD card port
17. On/Off Switch
Note: Press and hold any front-panel key or softkey to get context-sensitive help.
Front-Panel Number Entry
 You can enter numbers from the front panel in two ways:
Use the knob and cursor keys to modify the number. Rotate the knob to change a digit (clockwise
increases). The arrows below the knob move the cursor.
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
17
8
