17HARDI
®
N-SERIES 3-PT SPRAYER DIAPHRAGM OPERATOR'S MANUAL
3.4 Control box (electric controls only)
The HARDI
®
N-series 3-PT sprayer equipped with electric controls
uses an electrical control box for master on/off control and individual
boom section on/off control. An optional rate controller box is also
available.
1. Mount the control box in a convenient location near the operator.
2. Route the power supply (installed in section 3.3) to the small plug on
the control box.
3. Route the main wiring harness from the sprayer to the large plug on
the control box.
Fig. 7
