Harman Kardon AVR 10 User Manual

Specifications
ENGLISH
STEREO MODE
Continuous Average Power (FTC)
35 Watts from 20Hz-20kHz: @<0.09% THD,
both channels
driven into 8 Ohms
FIVE CHANNEL SURROUND MODE
Continuous average power per channel (FTC)
Front L&R channels
30 Watts from 20Hz-20kHz: @<0.3% THD,
both channels
driven into 8 Ohms
Center channel
30 Watts at 1kHz: @<0.3% THD,
driven into 8 Ohms
Rear channels
20 Watts at 1kHz: @<1.0% THD,
both channels
driven into 8 Ohms
AMPLIFIER SECTION
High-Instantaneous Current Capability
(HCC): ±20 Amps
Negative Feedback: 20dB
Frequency Response
@1W (+0/-3dB): 0.5Hz - 100kHz
Rise Time: 1.8µSec
Transient Intermodulation
Distortion (TIM): Unmeasurable
PREAMPLIFIER SECTION
Signal-to-Noise Ratio (ref. 1 Volt, A-Wtd)
CD: 92dB
Video 83dB
Input Sensitivity/Impedance
Video, CD, Tape: 150mV/22kΩ
Tone Control Range
Bass @ 50Hz: ±10dB
Treble @ 10kHz: ±10dB
TUNER SECTION: FM
(Normal mode)
Usable Sensitivity, Mono (dBf): 11.2
50dB Quieting Sensitivity,
Stereo (dbf): 40.3
Signal-to-Noise Ratio
@ 65dBf, mono/stereo: 70dB/65dB
Capture Ratio: 2.0dB
Selectivity, Adjacent/Alternate
Channel: 5dB/65dB
IF Rejection: 90dB
AM Rejection @ 45dBf: 55dB
Stereo Separation
@ 1kHz, 65dBf: 45dB
THD @ 1kHz, 65dBf,
mono/stereo (%): 0.2/0.4
TUNER SECTION: AM
Sensitivity, External Antenna: 25µV
Alternate Channel Selectivity 38dB
Image Rejection: 35dB
IF Rejection: 50dB
Dimensions (W × H × D):
inches: 17
5
/16 × 4
7
/8 × 14
15
/16
mm: 440 × 138 × 360
Weight (lbs/kgs): 18 lbs, 8.2 kg
Depth measurement includes knobs, buttons and jacks.
Height measurement includes feet.
All features and specifications are subject to change
without notice.
17
DECLARATION OF CONFORMITY
We, harman kardon Europe a/s
Kongevejen 194B
DK-3460 Birkerød
DANEMARK
declare that the product described in
this owner’s manual is in compliance
with technical standards:
EN 55020/6. 1988, EN 55013/6,
EN 60555/2, EN 60555/3
Accredited test laboratory:
MIKES PRODUCT SERVICE GmbH
Ohmstrasse 2-4
D-94342 Strasskirchen
GERMANY
95/7, Steen Michaelsen
harman kardon Europe a/s
The appliance conforms with EEC directive
87/308/EEC regarding interference suppression
AVR10 engelsk 11/01/98 10:11 Side 17

Harman Kardon AVR 10 Specifications

Power

continuous average power stereo mode	35 Watts from 20Hz-20kHz @ <0.09% THD, both channels driven into 8 Ohms
continuous average power five channel surround mode front L&R channels	30 Watts from 20Hz-20kHz @ <0.3% THD, both channels driven into 8 Ohms
continuous average power five channel surround mode center channel	30 Watts at 1kHz @ <0.3% THD, driven into 8 Ohms

Amplifier Section

high-instantaneous current capability (HCC)	±20 Amps
negative feedback	20dB
frequency response @ 1W (+0/-3dB)	0.5Hz - 100kHz

Weight and Dimensions

dimensions (W × H × D) inches	17 [5]/16 × 4 [7]/8 × 14 [15]/16
dimensions (W × H × D) mm	440 × 138 × 360
weight	18 lbs, 8.2 kg
