Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Device Type AVR Source Digital Audio Connection Analog Audio Connection Video Connections
Cable TV, satellite TV, HDTV CBL/SAT HDMI 2 Analog 1 HDMI 2
or other device that delivers
television programs
DVD Audio/Video, SACD, DVD HDMI 1 Analog 2 HDMI 1
Blu-ray Disc, HD-DVD player
Media Server, including Media Server Optical 2 Analog 5 S-Video 1
Harman Kardon DMC 1000
TV TV Optical 1 Analog 3 Component 1
*
Video game console Game HDMI 3 Analog 4 HDMI 3
Any audio or video device, AUX Coax Front Analog Front Composite Front (not used for
e.g. CD player, camcorder, audio-only devices)
cassette deck
Recorder Any Coaxial 1 or 2 input and Analog 4 inputs and outputs Composite OR S-Video 2 input
Coaxial Output and output
Portable audio player AUX Any Stereo Jack (use mini-plug Not required.
cable, not included)
*
Make this connection only when using the TV source for a non-display device. Do not connect your television’s or video display’s video output to the AVR at any time.
52 APPENDIX
APPENDIX – SETTINGS WORKSHEET
Table A2 – Source Setting Defaults
Cable/Sat DVD Media Server Radio TV Game AUX
Surround Modes (Auto Select) Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie Logic 7 Movie
Video Input HDMI 2 HDMI 1 S-Video 1 N/A Component 1 HDMI 3 Composite Front
Audio Input HDMI 2 HDMI 1 Optical 2 N/A Optical 1 HDMI 3 Coaxial Front
Resolution to Display 576i 576i 576i 576i 576i 576i 576i
Audio Auto Polling Analog 1 Analog 2 Analog 5 N/A Analog 3 Analog 4 Analog Front
Zone 2 Audio Analog 1 Analog 2 Analog 5 N/A Analog 3 Analog 4 Analog Front
