Harman® • Accentra 52i Owner’s Manual_R8 • 2013 -___ • 07/1422 3-90-00574c
Feeder Chamber
This chamber may get a buildup of nes from the feeder
mechanism movement. This area should be checked and
cleaned at least once a year.
To remove the feeder cover:
• Loosen the 5/16" wing nut Figure 5.12.
• Lift up and slide the cover off of the threaded stud.
• Inspect and clean the inner chamber if necessary. Figure
5.13.
• Reinstall the cover making certain it is seated properly on
the feeder body and tighten as tightly as you can by hand.
NOTE: Views are shown with the exhaust tube and covers
removed for better viewing.
Pellet Metering
Slide Plate
Possible pellet nes
buildup area.
Figure 5.13
5/16" Wing NutFeeder clean out cover
Figure 5.12
H. Pellet Feeder Chamber
