Harman Accentra Pellet Insert User Manual

5
3-90-00674R28_12/13
TheAccentraInsertismorethanjustautomaticignition,itis
alsoautomatictemperaturecontrol.Theautomaticsystemwill
allowtheresizetobeadjustedtomatchtheheatingneeds
andevenputthereoutifnecessary.Ifheatisneededafter
thereisout,theAccentraInsertwillautomaticallyre-ignite
andadjusttheresizetomatchtheheatingneed.Thetotally
automaticroomsensormodeisrecommendedbecauseof
itsefciency.Theunitcanbeswitchedbetween"AUTO"and
"MANUAL"atanytimeduringoperation.
Igniter switch to "AUTO"
Room Temperature Mode
In"RoomTempMode"heatoutputiscontrolledautomatically
bytheRoomSensingProbe.WhentheRoomSensingProbe
callsforheat,thestovewillincreaseoutput.WhentheRoom
SensingProbeisgettingclosetothesettemperature,the
stovewillbegintoleveloffoutputandkeepthereburning
atjusttherighttemperaturetomaintainthatsetting.
High output is determined by the feed rate setting. This
setting,generallyon#4,canbeincreasedifhigherburnrates
arenecessary(Fig.1).Theunit'smaximumburnrateshould
notcreatelessthan1"ofashontheburnpotfrontedge(See
Fig.2).Overfeedingisnotasafetyconcern,butfuelmaybe
wastedifunburnedpelletsfallintotheashpan.
In"RoomTempMode"aconstantfuelconsumptionrateis
sacricedforexactroomtemperature.Therefore,asitgets
coldermorepelletswillbeburnedautomatically.
The distribution blower speed will vary according to the
positionofthemodeselectorpointer,andresize.
Igniter switch to "AUTO"
Stove Temperature Mode
Thisallowsforautomaticignitionuponstart-uponly.Theunit
canthenbesetatanydesiredsetting.Theheatoutputand
fuel consumption will remain constant regardless of room
temperature (See Fig 4). The unit's maximum feed rate
shouldnotcreatelessthan1"ofashontheburnpotfront
edge.SeeFig2.
Theunit'slowburnormaintenancesettingisaslowasitwill
go.Itwillnotgooutunlessitrunsoutoffueloristurnedoff.
Shut-Down Procedure
To kill the re or stop burning the stove, turn the Mode
Selectorto"OFF".Thiswillcausetheretodiminishand
burnout.Whenthereburnsoutandthestovecoolsdown
everythingwillstop.
Ifyoupulltheplugtoshutdownthestove,allmotorswillstop.
Thismaycauseincompletecombustionandsmokeinthe
rebox.Iftheloaddoorisopened,thesmokemayescape.
Thebestwaytoshutdownthestoveissimplyletitrunout
ofpellets,thenthestovewillshutdownautomatically.
Automatic Ignition/Operation
Fig.4
Room Temperature Mode: This setting will produce a room temperature
of 70 degrees with the distribution blower at medium speed.
This setting will produce medium heat with the
distribution blower on "low".
This setting will produce continuous maximum heat
output with the distribution blower at full speed.
Stove Temperature Mode
Fig.3
