Specifications
Inputs
Connectors: Female XLR and 1/4” TRS (Pin 2 and tip hot)
Type: Electronically balanced/unbalanced, RF filtered
Impedance: Balanced > 50 k1, unbalanced >25 k1
Max Input Level: > +24 dBu balanced or unbalanced
CMRR: 40 dB; Typically >55 dB at 1 kHz
Outputs
Connectors: Male XLR and 1/4” TRS (Pin 2 and tip hot)
Type: Servo-balanced/unbalanced, RF filtered
Impedance: Balanced 1201, unbalanced 601
Max Output Level: > +21 dBu, >+20 dBm (6001) balanced/unbalanced
Sidechain Input
Connector: 1/4” TS
Type: Unbalanced, RF filtered
Impedance: > 10 kOhm
Max Input Level: > +24 dBu
Sidechain Output
Connector: 1/4” TRS (tip hot)
Impedance: Balanced 2 kOhm, unbalanced 1 kOhm
Max Output Level: > +21 dBu balanced or unbalanced
System Performance
Bandwidth: 20 Hz to 20 kHz, +0/-0.5 dB
Frequency Response: 0.35 Hz to 200 kHz, +0/-3 dB
Noise: < -95 dBu, unweighted, 22 kHz measurement bandwidth
Dynamic Range: > 120 dB, unweighted
THD+Noise: 0.008% typical at +4 dBu, 1 kHz unity gain
0.0496% typical at +20 dBu, 1 kHz, unity gain
< 0.1% any amount of compression up to 40 dB, 1 kHz
IMD: < 0.1% SMPTE
Interchannel Crosstalk: < -100 dB, 20 Hz to 20 kHz
VCA: dbx V2™
Stereo Coupling: True RMS Power Summing
Compressor
Threshold Range: -40 dBu to +20 dBu
Ratio: 1:1 to ':1
Threshold Characteristic: Selectable OverEasy® or hard knee
Attack/Release Characteristic: AutoDynamic™
Attack/Release Modes: Selectable Manual or Auto
Manual Attack Time: Scalable program-dependent. Typically 3 dB/msec to .04 dB/msec
Manual Release Time: Scalable program-dependent. Typically 250 dB/sec to 5 dB/sec
Auto Attack Time: Program-dependent. Typically 15ms for 10 dB, 5ms for 20 dB, and 3ms for 30 dB.
Auto Release Time: Program-dependent. Typically 125 dB/sec rate.Output Gain: -20 to +20 dB
Output Gain: -20 to +20 dB
Limiter
Threshold Range: +4 dBu to >+22 dBu (off)
Ratio: ':1
Limiter Type: PeakStopPlus™ two-stage limiter
Stage 1: Instantaneous Transient Clamp™
Attack Time: Zero
Release Time: Zero
Stage 2: Intelligent Predictive Limiting™
Attack Time: Program-dependent, typically <5 msec
Release Time: Program-dependent, typically 22 dB/sec
