5
510
Using The 510
To set the 510, follow these steps:
1. Start by setting the controls as shown below.
Disengaged
Off
2. Ensure the signal has sufficient bass content to process. While monitoring the signal, raise the 36 Hz–56 Hz control
until the desired amount of low-end enhancement is achieved within the frequency range.
3. Raise the 24 Hz–36 Hz control until the desired amount of low-end enhancement and roll-off is achieved within the
frequency range.
4. Adjust the SUBHARMONICS control to fine tune the amount of subharmonic processing applied to the signal.
5. Raise the LF BOOST control to fill in the “gap” between the generated subharmonics and the program material’s
lower-midrange frequencies. Note that the LF BOOST control can be used by itself if required. To do so, simply lower
the SUBHARMONICS control to the MIN setting to prevent generated subharmonics from being added to the
processed signal.
6. Use the BYPASS button to compare the processed and unprocessed signals to ensure the desired results have been
achieved.
