Harman JBL BAR 1300X User Manual

1010
4.2.2 Wall-mount the detachable speakers as rear
surround speakers
5
1
≥30 mm/1.18"
≤8 mm/0.31"
4mm/0.16"
2
4
3
1. From the soundbar, undock the two detachable speakers.
2. Install the wall-mounting bracket.
3. Fasten the support onto the back of the speakers.
4. Mount the speakers.
5. Install the side caps as needed.
5. CONNECT
5.1 Connection with your TV and digital
devices
For audio playback through the soundbar, connect the soundbar
with your TV through the supplied HDMI cable or an optical cable
(sold separately).
An HDMI connection supports digital audio and video with a
single connection. HDMI connectivity is the best option for your
soundbar.
5.1.1 TV (HDMI ARC / eARC)
(Recommended connection for the best Dolby Atmos / DTS:X
experience)
HDMI (ARC)HDMI (ARC)
*
HDMI OUT
HDMI INHDMI IN

Harman JBL BAR 1300X Specifications

General

Brand	Harman
Model	JBL BAR 1300X
Category	Speaker System
Language	English
