2) Calibrate the speaker position
L R
L R
2
PRESS CALIBR AGAIN
CALIBRATING
2-CALIBRATION
2DONE
RL
1. Place the detachable rear speakers in your desired location.
2. On the remote control, press CALIBR.
J “2-CALIBRATION” is displayed on the soundbar.
J Countdown starts from 5 to 1.
J Calibration tone is heard. Audio calibration starts.
“CALIBRATING”: Calibration in progress
“2-DONE”: Calibration of the speaker position is
completed successfully.
3. Rotate for the best listening experience.
NOTES:
– During sound calibration, all buttons on the remote control are
disabled except for and CALIBR.
6.3.2 Dolby Atmos
®
/ DTS:X
®
With Dolby Atmos or DTS:X, overhead audio distribution is
provided for powerful 3D sound immersion.
LOW
MID
HIGHLOW
MID
HIGH
MID HIGHLOW
1. To play the surround sound of DOLBY ATMOS or DTS:X,
connect and play your Blu-ray player or streaming device as
described under “5.1 Connection with your TV and digital
devices”.
2. To select suitable strength for Dolby Atmos or DTS:X, press
on remote control to toggle between middle (default),
high, or low.
6.3.3 Rear adjustment
With both of the detachable rear speakers undocked, you can
select the surround sound level.
LOW
MID
MUTE
HIGH
MID HIGH
MUTE
LOW
