Harman JBL BAR 700 User Manual

77
www.jbl.com
English
3.3 Subwoofer
1
2
1)
• Connection status indicator
Solid (white) Connected to the soundbar
Fast flashing (white) Pairing mode
Slow flashing (white)
Reconnecting or exiting the pairing
mode
Solid (amber) Standby mode
2) Power connector
• Connect to power (with the supplied power cord)
3.4 Remote control
8
7
6
5
4
1
2
3
1)
• Switch on or to standby
2) Source selectors
TV
• Select the TV source (default, for audio input from TV
connection where the HDMI OUT (TV ARC/ TV eARC)
connector is prioritized over the OPTICAL connector)
(Bluetooth)
• Select the Bluetooth source
• Press and hold to connect a Bluetooth device
HDMI
• Select the HDMI IN source
3) Sound effect buttons
• Switch the virtual Dolby Atmos
®
sound effects on or off
(Default: on)
• Select the bass level for subwoofer: 1/2/3 (default)/4/5

Harman JBL BAR 700 Specifications

General

Brand	Harman
Model	JBL BAR 700
Category	Speaker System
Language	English
