INSTRUMENTS & MIC PLUGGED INTO MIXER
CH1 XLR-1/4” Combo Mic, CH2 XLR-1/4” Combo Mic Keyboard
APPLICATION EXAMPLES
MICROPHONE
(presenter or speaker)
positioning distance
Microphone (speaker/presenter)
To prevent any unnecessary feedback, please:
Position Microphone at least 2m (6ft) from a speaker
Do not stand directly in front of a speaker
