10. SPECIFICATIONS
AC power input: 100 - 240 V ~ 50/60 Hz
DC power input: 12 V
4 A
Built-in battery: 72 Wh
Power consumption: 80 W
Standby power
consumption:
< 2 W with Bluetooth connection;
< 0.5W without Bluetooth connection
USB output: 5 V
2.1 A (Max.)
Speaker drivers:
2 x 6.5 inch (176 mm) woofers + 2 x
2.5 inch (65 mm) tweeters
Total output power:
240 W RMS (AC powered)
140 W RMS (battery powered)
140 W RMS (car powered)
Signal-to-noise (S/N)
ratio: > 80 dBA
Frequency response: 45 Hz - 20 kHz (-6 dB)
Battery charge time: < 3.5 hrs
*Battery play time: < 18 hrs
Bluetooth version: 5.1
Bluetooth prole: A2DP V1.3, AVRCP V1.6
Bluetooth transmitter
frequency range: 2.402 - 2480 MHz
Bluetooth maximum
transmitter power: 15 dBm (EIRP)
Bluetooth transmitter
modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth range: Approx. 10 m (33 ft)
USB format: FAT16, FAT32
USB le format: .mp3, .wma, .wav
Input sensitivity: Aux in: 250 mVrms
(3.5 mm connector)
Mic in: 20 mVrms;
Guitar in: 100 mVrms
Digital Input:
Bluetooth/USB -12 dBFS
Product dimension
(W x H x D):
325.6 x 687.7 x 367.8 mm/
12.8 x 27 x 14.5’’
Packaging dimension
(W x H x D):
792 x 430 x 388 mm /
31.18 x 16.93 x 15.28’’
Net weight: 17.4 kg / 38.4 lbs
Gross weight: 19.1 kg / 42.11 lbs
* 18 hrs battery playtime is only a reference and may vary depending
on music content and battery aging after numerous charging and
discharging cycles. It’s achievable with a predened music source, light
show switched off, volume level at 18 and Bluetooth streaming source.
9.7 IPX4
Caution:
– Always keep the charging port dry before connecting AC power.
– To ensure splash resistance, always keep the protective covers
closed securely.
The speaker is IPX4 splash resistant.
