JBL BRX300 SERIES
SYSTEM SPECIFICATIONS
The BRX300 Series is a system that ships as dierent SKU’s to enable ease of transportation. The models are meant
to be used together. The specications below are for the systems.
Frequency Range (-10 dB) 32 Hz–20 kHz
Frequency Response (-3 dB) 40 Hz–19 kHz
Max Rated SPL SUB: 136 dB, TOP: 136 dB
System Components SUB: 2 x 15”, TOP (each): 2 x 8” LF + 1 x 3” titanium compression driver
Nominal Coverage (H x V) 110° x 12° each element (vertical coverage is a function of inter-box angles)
System Input Connectors AMP MODULE: 2 x balanced XLR-F wired in parallel to XLR-M for THRU outputs
TOP: 2 x 4-pole NL4 connectors wired in parallel for IN/THRU use
System Output Connectors AMP MODULE: 2 x 4-pole NL4 connectors for powering up to 4 x TOPS
System Power Input 1 x 20A PowerCon, system input voltage is 230 VAC only
Dimensions (H x W x D) TOP: 299 x 662 x 376 mm
SUB: 890 x 690 x 693 mm
Weight TOP: 20.5 kg each
SUB: 86 kg
BRX308-LA SPECIFICATIONS
The BRX300 Series is a system that ships as dierent SKU’s to enable ease of transportation. The models are meant
to be used together. The specications below are for shipping purpose only.
Frequency Range (-10 dB) 80 Hz–20 kHz
Frequency Response (-3 dB) 100 Hz–19 kHz
Max Rated SPL 136 dB
System Components 2 x 8” LF + 1 x 3” titanium compression driver
Nominal Coverage (H x V) 110° x 12° each element (vertical coverage is a function of inter-box angles)
System Input Connectors 2 x 4 pole NL4 connectors wired in parallel for IN/THRU use
Dimensions (H x W x D) 299 x 662 x 376 mm
Weight 20.5 kg each
BRX325SP SPECIFICATIONS
The BRX300 Series is a system that ships as dierent SKU’s to enable ease of transportation. The models are meant
to be used together. The specications below are for shipping purpose only.
Frequency Range (-10 dB) 32 Hz–250 Hz
Frequency Response (-3 dB) 40 Hz–150 Hz
Max Rated SPL 136 dB (calculated based on sensitivity and power ratings)
System Components 2 x 15”
System Input Connectors AMP MODULE: 2 x balanced XLR-F wired in parallel to XLR-M for THRU outputs
System Output Connectors AMP MODULE: 2 x 4-pole NL4 connectors for powering up to 4 x TOPS
System Power Input 1 x 20A PowerCon, system input voltage is 230 VAC only
Dimensions (H x W x D) 890 x 690 x 693 mm
Weight 86 kg
SPECIFICATIONS
