Harman® • P42i Owner’s Manual • 2023 -___ • 03/2314 8742-900A
AftertheHeatExchangerhasbeenscraped,usethedust
brushsuppliedtoremoveanyremainingy-ashfromtheHeat
Exchanger as well as otherareas throughoutthe rebox.
Figure2.5.
Figure 2.5
BrushthereboxfreeofremainingFly-Ash.
Figure 2.6
Cleaning the Burn Pot-
• Vigorously scrape the top holed surface and sides of the
burn pot down to auger tube, as suggested in the Daily/
WeeklyMaintenanceSection.
• Usethesuppliedallenwrenchtoremoveanybuild-upthat
may have accumulated in the holes of the burn pot grate.
Simply push the allen wrench down through each hole
ensuringitisclearofanybuild-uppayingattentionnotto
damage the igniter element in the process. Figure 2.6.
Disconnect the power to the unit before removing
cover.
DANGER
• Loosenthe(2)wingthumbscrewsonthelowerfrontangle
of the burn pot. Figure 2.7
• Lifto󰀨theclean-outcovertoopenthebottomclean-out
chamber. Figure 2.8
• Clean ash buildup from inside the chamber while cover
iso󰀨.Usethescrapertotaponthetopfrontedgeofthe
burn pot. This will help knock pieces of ash, loosened by
thescrapingprocess,downthroughtheholes.Italsohelps
knock ash buildup from the igniter element and bracket.
Clean Ash Accumulation
Figure 2.8
Figure 2.7
WingThumbScrews
