Harman Uconnect VP4 940 User Manual

MODEL: VP4 940
SETTING THE PRESETS
Presets are available in all system
modes and are activated by touching
one of the preset buttons located in the
upper area of the display.
If you are tuned into a radio station that
you wish to store, hold down the button
on the display which corresponds to
❒ "Loudness" (for versions/markets,
where provided)
❒ "Auto-On Radio".
To exit the "audio" menu, press the
/Done button.
NOTE When a setting is changed, the
button is replaced with the word
"Done".
Balance/Fader
Press the "Balance/Fader" button to
adjust the balance of the sound from
the front and rear seat speakers.
Press the or buttons to adjust the
balance of the front and rear speakers
(see fig. 7).
the desired preset until an acoustic
confirmation signal is emitted.
The system can store up to 12 radio
stations in each mode: 4 of these
are displayed in the upper area.
Press the "browse" button on the
display to show all the radio stations
Equalizer
(for versions/markets, where provided)
Select the "Equalizer" option on the
display to adjust the bass, medium and
treble tones.
Then use the "+" or "–" buttons to
FM 99.60
Settings > Audio
Balance/Fade
Equalizer
Speed
Adjusted Vol.
10:10
SW
stored in the selected frequency band.
AUDIO SETTINGS
make the desired adjustments (see fig.
6).
7
A0K2038
Press the or buttons to adjust the
The Audio Settings menu, which can be
accesses by pressing the "audio"
button at the bottom of the display, can
FM 99.60
Settings > Audio
10:10
balance of the speakers on the left
SW
and the right side.
be used to change the following
settings:
❒ "Equalizer" (for versions/markets,
where provided)
❒ "Balance/Fader" (left/right and
front/rear audio balance adjustment)
Balance/Fade
Equalizer
Speed
Adjusted Vol.
Treble Treble
Mid Mid
Bass Bass
The adjustment is also possible by
moving the symbol on the right side
of the display upwards/downwards/to
the left/to the right.
Press the central "C" button to balance
the adjustments.
❒ "Volume/Speed" (excluding versions
with Hi-Fi system) automatic
speed-dependent volume adjustment
14
6
A0K2039
Once the adjustments are complete,
press the /Done button to return to
the "Audio" menu.
Once the adjustments are complete,
press the /Done button to return to
the "Audio" menu.
