Harman XXV Installation & Operating Manual

31
XXV Pellet Stove
Description Part Number
Hopper Gasket(6 ft.) 3-44-375501
Ash Pan Assembly 1-10-677044
Burn Pot Weldment 1-10-00675
Right Rear Shield 1-10-677085
Left Rear Shield 1-10-677084
Arrow Scraper 2-00-773850
Flame Guide 3-00-03000
Wiring Harness Assembly 3-20-08727
Thermister Probe 3-20-00744 or 3-20-00844 (red wire)
Room Sensor 3-20-00906
Circuit Board 3-20-05374 or 3-20-05886 (match w/old)
Differential Switch 3-20-6866
5" Double Fan Blade 3-20-502221
Combustion Blower 3-21-08639
Distribution Blower 3-20-29045A
Hopper Lid Latch 2-00-06697
Hopper Lid Knob 3-43-02000-8
Hopper Lid Glass 3-40-247100
Hopper Lid Screws 3-31-129004
Hopper Lid Gasket (4 ft) 3-44-375501
Wood Handle 3-40-00123
Ash Door Gasket (3 ft) 3-44-00539
Glass Gasket (5 ft) 3-44-1186258229
Load Door Gasket (6 ft) 3-44-53716
Ball Plunger 3-31-5500
Rocker Switch 3-20-07625
Power Cord 3-20-29685
White/Black Control Knob(3) 3-31-605
Control Knob Shaft(3) 3-31-015
Mirrored Front Glass 3-40-677000
Burn Pot Gasket(1) 3-44-00409
Tailpipe Gasket 3-44-06179
Wiring Diagram 3-90-00677
Control Panel Sticker 3-90-247155A
Owner's Manual 3-90-00684
Hopper Hinge Label 3-90-09416
Igniter Assembly 3-20-06783
Cleanout Cover(1) 2-00-06623
1/4-20 x 1/2" Wing Screw w/Collar(2) 3-31-782108
Mufer 3-40-6618
Mufer Fitting 3-40-1818
Hopper Throat Gasket 3-44-677185
Top Vent Option 1-00-677120
Direct Vent Wall Passthrough 1-00-677077
25' Flex Pipe 1-00-08543
Battery Back Up 3-20-512
Floor Protector 1-00-677036
