Hayward SharkVAC General Information

Maintenance.
Clean the filter cartridge after each use:
• Open the SharkVAC by pressing the lid button & lifting up the dome cover
• Remove the filter bucket assembly by lifting it up out of the SharkVAC with
both hands from each side.
• Flip the bucket assembly over to remove the debris & then rinse with a garden
hose to remove small particles. Filter cartridges do not need to be removed
to clean

Hayward SharkVAC Specifications

Power

current consumption	0.78 amps
primary voltage	110-120 volt AC (220-240 volts for 240 volt model)
secondary voltage	24V DC

Motor Specifications

speed	2, 700 rpm
voltage	24V DC, 22V DC, 5V DC
current	2.62 amps, 0.63 amps

Filter

filter type	removable, re-usable, pleated element cartridge
filter porosity	100 micron
filter area	1, 150 sq. inches

Weight and Dimensions

weight without cable	21.5 lbs
cable length	50 ft
shipping weight	21.5 lbs (19.1 kg)
