Num

ber

Descripon

Note

The funcon of GPRS or 3G/4G (implemented

with built-in SIM card slot) varies depends on

the model of the device.

7 TAMPER

8 Reset Buon

9 AP&STA Switch

10 Baery Connector

11 Network Interface

12 Power Interface

Funcon Buon

The funcon buon is on the side of the control panel.

Figure 1-3 Funcon Buon

Use the funcon buon to add wireless devices and check the RF

signal.

While the control panel is not in the conguraon mode, press

the

funcon buon on the side of the control panel once and

trigger a peripheral device.

While the control panel is not in the conguraon mode, double

press the funcon buon, and you can check the RF signal

strength on the peripheral device.

Result

RSSI Acon

Strong Over 160 OK to install

Medium 113 to 160 OK to install

Weak 0 to 112

Please see the note

below.

Invalid - Not OK to install

HIKVISION AXHub User Manual
