HIKVISION DS-2AE5232T-A User Manual

HD-TVI Speed Dome User Manual
18
Task 12: Configure the image quality.
 Wide Limit
Set the value of WIDE LIMIT to limit the minimum zoom of the lens with 1.0, 1.1, 1.2, 1.3, 1.5, 1.8
and 2.0 available.
The Wide Limit function is supported by certain speed dome model series.
 Chroma Suppress
Set the Chroma suppress value from 1 to 3 to suppress the color noise so as to get the clear and
high-quality image in the low luminance environment.
The Chroma Suppress function is supported by certain speed dome model series.
 Saturation
Saturation value from 0 to 7 indicates the brightness of the color. The higher the saturation, the
brighter the color is.
The saturation function is supported by certain speed dome model series.
 Scene Mode
Select the scene mode as INDOOR or OUTDOOR, and the default image settings will be changed
according to the selected scene mode.
 Contrast
Contrast is the degree of difference between the darker and lighter parts of the image.
The contrast function is supported by certain camera model series.
 HLC
Set the value of HLC to brighten the darker area and weaken the highlight area of the image. The
greater the value, the stronger the effect will be.
The HLC function is supported by certain camera model series.
 Sharpness Compensation
Set the value from 0 to 15 of SHARPNESS COMP to automatically adjust the sharpness of the image
to get a clear image. The greater the value is, the stronger the effect will be.
Task 13: Configure the defog parameters.

HIKVISION DS-2AE5232T-A Specifications

General

Image Sensor	1/2.8" Progressive Scan CMOS
Effective Pixels	1920(H) x 1080(V)
Signal System	PAL/NTSC
Gain	Auto/Manual
Digital Zoom	16x
Max Resolution	1920 × 1080
Pan Range	360° Endless
Tilt Range	-15°~90° (Auto Flip )
Presets	256
Patrol Scan	8
Power Loss Recovery	Support
IR Range	Up to 150m
Protection Level	IP66
Camera Type	PTZ Camera
White Balance	Auto/Manual/Indoor/Outdoor
Shutter Time	1/1 s to 1/10, 000 s
Day & Night	IR Cut Filter
Lens	32× Optical Zoom
Zoom	32x Optical, 16x Digital
Minimum Working Distance	10 mm to 1500 mm (Wide-Tele)
Video Compression	H.264
Frame Rate	50Hz: 25fps (1920 x 1080), 60Hz: 30fps (1920 x 1080)
Tilt Speed	Tilt Preset Speed: 200°/s
Proportional Zoom	Support
IR intensity	Auto/Manual
Network Interface	RJ45 10M/100M Ethernet
Power Supply	24 VAC
Power Consumption	Max. 30W
Working Temperature/Humidity	-30°C to 65°C (-22°F to 149°F) / Humidity 90% or less (non-condensing)
Privacy Masking	Up to 24 areas
Auto Focus	Auto / Semi-automatic / Manual
Dimensions	Φ 220 mm × 353.4 mm (Φ 8.66" × 13.91")
Min. Illumination	Color: 0.05 Lux @(F1.6, AGC ON), B/W: 0.01 Lux @(F1.6, AGC ON)
