User Manual of HD-TVI Speed Dome
© Hikvision
34
Up to 8 time tasks can be configured.
3. Set the task status.
Steps:
(1) Move the cursor to ENABLE TASK and click IRIS+ to enter edit mode.
(2) Click the up/down direction buttons to set the task status to ON.
(3) Click IRIS+ again to confirm the settings and exit edit mode of this column.
If the task action and task time have not been configured, you cannot set the status as ON.
4. Configure the task action.
Steps:
(1) Move the cursor to TASK ACT and click the IRIS+ to enter edit mode.
(2) Click the up and down direction buttons to select the task action from preset 1~8, pattern
1~5, patrol 1~10, pan scan, tilt scan, random scan, frame scan, panoramic scan, day mode,
night mode, zero calibrate and none.
(3) Click IRIS+ again to confirm the settings and exit edit mode of this column.
5. Set the task time.
Steps:
(1) Move the cursor to TASK TIME and click IRIS+ to enter edit mode.
(2) Click the left and right direction buttons to position the cursor to WEEK, START (H-M) and
END (H-M).
(3) Click the up and down direction buttons to set the start time and end time to run the time
task.
(4) Click IRIS+ to confirm the settings and exit.
The weekday can be set to be from Monday to Sunday or Whole Week; the H refers to
Hour and the M refers to Minute.
WEEK WHOLE WEEK
START(H-M) 00 00
END(H-M) 00 00
IRIS+ OK
IRIS- CANCEL
Figure 3-18 Set the Task Time
6. Delete the task.
Move the cursor to TASK CLEAR, click IRIS+ to delete the time and action of the current task,
and click IRIS+ again to confirm the settings and exit.

HIKVISION DS-2AE7230TI-A Specifications

General

Type	CCTV security camera
PTZ control	Yes
Languages support	CHI (SIMPL), ENG
Number of languages	2
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	120 m
Pan range	0 - 360 °
Pan speed	240 °/sec
White balance	ATW, Auto, Indoor, Manual, Outdoor
Tilt angle range	-15 - 90 °
Camera shutter speed	PAL: 1-1/10000s, NTSC: 1-1/10000s s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Effective sensor resolution	1920 pixels
Interface	BNC
AC input voltage	24 V
Power consumption (max)	30 W
Power over Ethernet (PoE)	No
Form factor	Dome
Mounting type	Desk/Wall
Product color	White
International Protection (IP) code	IP66
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	50 dB
Digital zoom	16 x
Optical zoom	30 x
Focal length range	4 - 120 mm
Maximum aperture number	4.4
Number of cameras	1
Operating temperature (T-T)	-30 - 65 °C

Weight and Dimensions

Height	353.4 mm
Weight	4500 g
Diameter	220 mm
