User Manual of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
If there is not a WPS button on the camera, you can also click the virtual button to
enable the PBC function on the web interface.
Click button.
When the PBC mode is both enabled in the router and the camera, the camera and
the wireless network is connected automatically.
PIN Mode:
The PIN mode requires a Personal Identification Number (PIN) to be read from either
a sticker or the display on the new wireless device. This PIN must then be entered to
connect the network, usually the Access Point of the network.
Steps:
1. Choose a wireless connection on the list and the SSID is shown.
Figure 4-8 Wi-Fi Settings – WPS PIN Mode
2. Choose the .
If the PIN code is generated from the router side, you should enter the PIN code you
get from the router side in the field.
3. Click button.
Or
