Network Camera User Manual
49
232 should be the same with the parameters you configured here.
3. Click Save to save the settings.
Configuring RS-485 Settings
Purpose:
The RS-485 serial port is used to control the PTZ of the camera. The configuring of the
PTZ parameters should be done before you control the PTZ unit.
Note: Only certain camera models support this function.
Steps:
1. Enter RS-485 Port Setting interface: Configuration > System > System Settings >
RS-485.
RS-485 Settings
2. Set the RS-485 parameters and click Save to save the settings.
By default, the Baud Rate is set as 9600 bps, the Data Bit is 8, the stop bit is 1 and
the Parity and Flow Control is None.
Note: The Baud Rate, PTZ Protocol and PTZ Address parameters should be exactly the
same as the PTZ camera parameters.
6.2.6 Configuring VCA Resource
Purpose:
VCA resource offers you options to enable certain VCA functions according to actual
need when several VCA functions are available. It helps allocate more resources to the
desired functions.
