HIKVISION DS-3E1106HP-EI User Manual

Chapter 2 Installaon
Please select the appropriate installaon method according to the actual needs.
Before You Start
• Ensure that the desktop or wall is stable and
rm enough.
• Keep the room well-venlated. Keep at least 10 cm distance around the device for heat
dissipaon.
2.1 Desk-Mounted Installaon
Place the device on the desk.
2.2 Wall-Mounted
Installaon
Before You Start
Prepare the tools.
Steps
1. Check the distance between the two hanging holes on the rear cover of the device.
2. Insert two M4 screws into the wall.
Note
• Ensure that the distance between the two screws equals to the distance between the two
hanging holes.
• Set aside at least 4 mm screws outside the wall.
3.
Align the hanging holes with screws, and hang the device on the screws.
Figure 2-1 Wall-Mounted Installaon
100 Mbps Hi-PoE Switch Quick Start Guide
4
