HIKVISION DS-7216HVI-ST User Manual

Hikvision Technical Manual
©2006
–
2011 by HIKVISION. All rights reserved.
Functions & Performances
Compression
 PAL/NTSC adaptive video inputs.

H.264 video compression with high reliability and superior definition.

G.711 audio compression standard.
 Independent video encoding parameters, including frame rate,
resolution, bit rate, video quality, etc.

Scheduled and event recording parameters configurable for per
individual camera.
 Support dual stream.
 Encoding for both audio/video composite stream and video stream;
audio and video synchronization during composite stream encoding.
 Compression, storage and network transmission of video image at 4CIF
or CIF resolution.
 Watermark technology.
Local Monitoring
 Up to 1024×768 resolution for VGA output display.
 Simultaneous VGA and CVBS output.
 1/4/9/16-camera video live view, with the camera order adjustable.
 Group switch, manual switch and automatic cycle modes selectable for
video live view, with the auto cycle period configurable.
 Digital zoom in live view mode.
 Shield of assigned channel for live view.
 Privacy masking capability.
 Multiple PTZ protocols supported, and settings and callup of presets,
patrols and patterns.
 Video image zoom-in by clicking the mouse and tracing by dragging
mouse in PTZ control mode.
Hard Disk Management
 Connection to 2 SATA hard disks supported, with up to 2TB storage
capacity.
 S.M.A.R.T technology.

HDD standby function.
 HDD file system is compatible with Windows. Use pre-allocating hard
disk management technology, and no disk fragments.
Recording
 Cycle and non-cycle recording mode.

Scheduled and event video encoding parameters.

HIKVISION DS-7216HVI-ST Specifications

General

Brand	HIKVISION
Model	DS-7216HVI-ST
Category	DVR
Language	English
