Hikvision Technical Manual
©2006
–
2011 by HIKVISION. All rights reserved.
Rear Panel & Interfaces
Rear Panel of DS-7216HVI-ST
①
MAIN/SPOT VIDEO OUT
②
VIDEO IN
③
AUDIO IN
④
LINE IN
⑤
AUDIO OUT
⑥
VGA Interface
⑦
RS-232 Serial Interface
⑧
LAN
⑨
USB Interface
⑩
RS-485 Interface
⑪
ALARM IN, ALARM OUT
⑫
12VDC Power Supply Interface
⑬
POWER
⑭
GND
