Quick Operation Guide of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR
32
3. The online cameras with same network segment will be displayed in the camera list. Click the button to
add the camera.
Note: The added camera is marked in white while the camera has not been added is marked in yellow.
Table 24 Explanation of the icons
Icon Explanation Icon Explanation
Edit basic parameters of the camera Add the detected IP camera.
The camera is connected.
The camera is disconnected; you can click
the icon to get the exception information of
camera.
Delete the IP camera. Advanced settings of the camera.
4. To add other IP cameras:
1) Click the Custom Adding button to pop up the Add IP Camera (Custom) interface.
2) You can edit the IP address, protocol, management port, and other information of the IP camera to be
added.
3) Click Add to add the camera.
4) (For the encoders with multiple channels only) check the checkbox of Channel No. in the pop-up
window, as shown in the following figure, and click OK to finish adding.

HIKVISION DS-7308HWI-SH Specifications

General

Product color	Black
Channels quantity	8 channels
Maximum frame rate	30 fps
Total storage capacity	12000 GB
Video compression formats	H.264
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x576, 704x480
Audio input	4
RS-485 ports	1
BNC input ports	8
BNC output ports	2
USB 2.0 ports quantity	3
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power requirements	100-240 VAC, 5A, 50-60Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 390 x 70 mm
