Specifications of DS-7100NI-SL
Model
DS-7104NI-SL
DS-7108NI-SL
Video/Audio
input
IP video input
4-ch
8-ch
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
25Mbps
50Mbps
Outgoing bandwidth
40Mbps
Remote connection
32
128
Video/Audio
output
Recording resolution
1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720
/60Hz, 1024 × 768 /60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Playback resolution
1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
Synchronous
playback
4-ch@720P, 2-ch@1080P
8-ch@4CIF, 4-ch@720P,
2-ch@1080P
Hard disk
SATA
1 SATA interface for 1 HDD
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface
USB interface
2 × USB 2.0
Others
Power supply
12VDC
Consumption
≤ 15 W (without hard disk)
Working temperature
-10 ºC ~ +55 ºC (+14 ºF ~ +131 ºF)
Working humidity
10 % ~ 90 %
Chassis
1U chassis
Dimensions
(W × D × H)
200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
Weight
≤ 1 Kg (2.2 lb)( without hard disk)

HIKVISION DS-7732NI-E4 Specifications

General

Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	4
HDMI output	Yes
Audio RCA inputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
HDD interface	Serial ATA
Maximum storage capacity	24 TB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	4000 g
