HIKVISION DS-K1104MK User Manual

DS-K1100 Series Card Reader
3
The front view of DS-K1104 series card reader is shown below:
Figure 1-7 DS-K1104MK/DS-K1104CK
Figure 1-8 DS-K1104M/DS-K1104C
1.2 Rear View
The rear view of card reader is shown below:
1
2
3
4
5
Figure 1-9 Rear View of DS-K1101 Series

HIKVISION DS-K1104MK Specifications

General

Quantity per pack	1 pc(s)
Internal	No
Product color	Black, Silver
Built-in processor	Yes
Compatible memory cards	-
RS-485 ports	1
Type	Basic access control reader
Certification	FCC, CE
LED indicators	Status
RFID frequency	13.56 MHz
Authentication type	Access chip/card, Password
Supported protocols	Mifare
Keypad number of keys	12
RFID reading distance	50 mm
International Protection (IP) code	IP65
Operating temperature (T-T)	-20 - 65 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption	0.5 mA

Weight and Dimensions

Depth	23 mm
Width	76 mm
Height	118 mm
Weight	520 g
