HIKVISION DS-K2800 Series Quick Start Guide

DS-K2800 Serial Access Controller
4
Chapter 2 Appearance
Component Description
Access Controller Component Schematic Diagram
Take DS-K2804 as an example, the component schematic diagram is shown below.
Figure 2-1 DS-K2804 Component Schematic Diagram
DS-K2800 Component Description Table 2-1
No.
Component Description
DS-K2801
DS-K2802
DS-K2804
1
Door Lock 1
Indicator
Door Lock 1/2
Indicator
Door Lock 1/2/3/4
Indicator
2
Power Indicator
3
Network Indicator

HIKVISION DS-K2800 Series Specifications

General

Brand	HIKVISION
Model	DS-K2800 Series
Category	IP Access Controllers
Language	English
