HIKVISION DS-K2800 Series User Manual

Access Control Terminal·User Manual
4
No.
DS-K2801
A8
SENSOR
Door Magnetic detector
B1
Alarm Output
COM
Alarm Relay Output (Dry Contact)
B2
NO/NC
B3
Alarm Input
GND
Grounding
B4
IN
Event Input
B5
Wiegand Card
Reader 1
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B6
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B7
BZ
Card Reader Buzzer Control Output
B8
W1
Wiegand Head Read Data Input
Data1
B9
W0
Wiegand Head Read Data Input
Data0
B10
PWR
Card Reader Power Output
B11
GND
B12
Wiegand Card
Reader 2
OK
Indicator of Card Reader Control
Output (Valid Card Output)
B13
ERR
Indicator of Card Reader Control
Output (Invalid Card Output)
B14
BZ
Card Reader Buzzer Control Output
B15
W1
Wiegand Head Read Data Input
Data1
B16
W0
Wiegand Head Read Data Input
Data0
B17
PWR
Card Reader Power Output
B18
GND
