HIKVISION DS-KIS202 User Manual

Video Door Phone·User Manual
12
Appendix
Installation Notice
While installing the indoor station, make sure that the distance between any two
devices is far enough to avoid the howling and echo. The distance between two devices
is recommended to be longer than 10 meters.
Here devices refer to indoor stations, and door stations.
Specification
Specification of DS-KH2220
Model
Parameters
DS-KH2220
Display parameters
Display screen
7-Inch Colorful TFT LCD
Resolution
800 × 480
Operation method
Physical Button
Audio parameters
Audio input
Build-in Omnidirectional Microphone
Audio output
Build-in Loudspeaker
Audio quality
Noise Suppression and Echo Cancellation
Device interfaces
Four-wire interface
4 Four-Wire Interfaces
1-ch Video Input, 1-ch Audio Input/Output, 1-ch Power
Supply, 1-ch Grounding
General
Power supply
12 VDC
Power consumption
Max. 5W
Working temperature
-10° C to +55° C (14° F to 131° F)
Working humidity
10% to 90%
Dimension (L x W x H)
195.8 mm × 132.8 mm × 18.39 mm (7.7" × 5.2" ×0.7")

HIKVISION DS-KIS202 Specifications

General

Camera included	Yes
Connectivity technology	Wired
Maximum number of cameras supported	1
Display diagonal	7 \
Display resolution	800 x 480 pixels
Display technology	TFT
Megapixel	1 MP
Sensor type	CMOS
Maximum frame rate	25 fps
Optical sensor size	1/4 \
Maximum video resolution	720 x 576 pixels
Product color	White
Housing material	Aluminum
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	5 W

Weight and Dimensions

Depth	42 mm
Width	128 mm
Height	24.8 mm
Power supply dimensions (WxDxH)	195.8 x 132.8 x 18.39 mm
