Digital Video Recorder User Manual
130
Chapter 9 VCA Alarm
Purpose
The DVR can receive the VCA alarm (line crossing detection, intrusion detection, sudden scene
change detection and audio exception detection) sent by analog camera, and the VCA detection
must be enabled and configured on the camera settings interface first. All other VCA detection
features must be supported by the connected IP camera.
For HWD-7100MH and HWD-7200MH series DVR, if enhanced VCA mode is enabled,
full-channel line crossing detection and intrusion detection, and 2-ch sudden scene change
detection are supported, but 2K/4K output and 4 MP/5 MP/8 MP signal input are not
supported; if enhanced VCA mode is disabled, 2-ch line crossing detection and intrusion
detection, and 2-ch sudden scene change detection are supported, and 2K/4K output and 4
MP/5 MP/8 MP signal input are also supported.
HWD-6200MH-G2 series support up to 4-ch line crossing detection and intrusion detection if
enhanced VCA mode is enabled. HWD-6216MH-G2 series also support 1-ch sudden scene
change detection. Channels with audio support audio exception detection.
For the analog channels, the line crossing detection and intrusion detection conflict with
other VCA detection such as sudden scene change detection, face detection and vehicle
detection. You can only enable one function.
9.1 Face Detection
Purpose
Face detection function detects the face appears in the surveillance scene, and some certain actions
can be taken when the alarm is triggered.
Step 1 Go to Menu > Camera > VCA.
Step 2 Select the camera to configure the VCA.
You can check the checkbox of Save VCA Picture to save the captured pictures of VCA
detection.
