HIKVISION HWT-B323-Z User Manual

Digital Video Recorder User Manual
90
Figure 6-2 Right-click Menu under Live View
Playback by Time
Purpose
Play back video files recorded in specified time duration. Multi-channel simultaneous playback and
channel switch are supported.
Step 1 Go to Menu > Playback.
Step 2 Check the checkbox of channel(s) in the channel list and then double-click to select a date
on the calendar.
Figure 6-3 Playback Calendar
If there are record files for that camera in that day, in the calendar, the icon for that day is displayed as
. Otherwise it is displayed as .

HIKVISION HWT-B323-Z Specifications

General

Model	HWT-B323-Z
Category	Security Camera
Type	Bullet Camera
Image Sensor	2 MP CMOS
Signal System	PAL/NTSC
Resolution	1920 x 1080
Min. Illumination	0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
IR Range	Up to 40 m
IR Distance	40 m
WDR (Wide Dynamic Range)	Digital WDR
Video Output	1 HD analog output
Operating Temperature	-40 °C to 60 °C (-40 °F to 140 °F)
Power Supply	12 VDC ± 25%
Protection Level	IP67
Material	Metal
Day & Night	IR cut filter
Video Frame Rate	30fps @ 1080p
Operating Conditions	-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Operating Humidity	90% or less (non-condensation)
