Network Box Camera·Quick Start Guide
21
Install Camera to Mounting Plate
2. Screw the mounting plate together with the camera back to the
housing.
Note:
Push the camera as close to the window as possible.
Window
Cable Outlet
Install Camera to Housing
3. Connect and route cables through the cable outlet of the housing.
