Network Box Camera·Quick Start Guide
25
Adjustment
Screw
Wall Mount
Pole
Pole Mount
Adjustment
Screw
Figure 2-14 Fix the Housing to Brackets (1)
Pendant
Mount
Adjusting Screw
Figure 2-15 Fix the Housing to Brackets (2)
6. Adjust zoom and focus. Refer to Section 2.5.
2.4.2 Mounting Type II Housing
Steps:
1. Connect and route cables through the cable outlet of the housing.
