5
TV Rear
TV Rear
Power Input
ANT
HDMI 3
(
4K@30Hz
)
HDMI 2
ARC
(
4K@60Hz
)
HEADPHONE HDMI 1
(
4K@60Hz
)
DC 5V 1A(MAX)
USB 1
DC 5V 0.5A(MAX)
USB 2
SERVICE
LAN
HDMI 4
(4K@30Hz)
NOTES
Check the jacks for position and type before making any connections. Loose
connections can result in image or color problems. Make sure that all connections
are tight and secure.
The TV may not be compatible with all external devices. To check compatibility,
please refer to the user manual of external device.
Do not connect external equipment while TV's power cord is plugged in. It may
cause electric shock.
Service jack is not available for you to connect an external device. It can only be
used by our factory for testing
purposes.
Note: There's one screw at the
place of arrow and it is usually
covered by an AC INPUT label.
VIDEO L R
AV IN
AUDIO
DIGITAL
AUDIO OUT
