2
CAUTION
Be sure to disconnect the A/C power cord before removing a base stand or
installing Wall-Mount brackets.
The screen display is very fragile, and must be protected at all times when installing
the base stand. Be sure that no hard or sharp object, or anything that could scratch
or damage the screen display, comes into contact with it. DO NOT exert pressure
on the front of the TV at any time because the screen could crack.
Follow the illustrations and textual instructions below to complete the installation steps:
Installing the Stand
Installing the Stand or Wall Mount Bracket
1. Carefully place your TV face down on a soft, flat surface to prevent damage to the
TV or scratching to the screen.
2. Remove the 2 base stand from the foam and then insert the base stand into the
bottom slots of the TV.
3. Use the screws that came inside the carton with your TV to secure each base stand
tightly.
base stand
base stand
Screws: M4 × 20
Screws: M4 × 20
