- 12 -
2.2 Main Board:
K15 Series
Note
：
The above “Main board image”is only take LHDN32K15CEU for example, others please refer to the
actual units to determine the boards.
Main IC
（MSD308）
DDR2（512M）
DDR2（512M）
Flash
Digital Audio AMP
LVDS OUT
Y/Video PB PR L R
VGA
PC Audio IN
USB
HDMI
Earphone
SCART
