Hisense LCD19W57ACA User Manual

- 14 -
LCD TV Service Manual
Hisense Confidential
4. Chassis Layout and Overall Wiring Diagrams
4.1 Chassis Layout
LCD19W57ACA
No Description Part No. Type/Model PCB/ Model
(1)
Main Board 120130 RSAG2.908.1544-1\ROH 3RSAG7.820.1701\VERB\ROH
(2)
Power Board 117925 RSAG2.908.1453\ROH RSAG7.820.1569\VER.D\ROH
(3)
Keypad PCA 114552 RSAG2.908.1168-2\ROH 20RSAG7.820.1214\VER.A\ROH
(4)
IR Board 114175 RSAG2.908.1169\ROH 40RSAG7.820.1213\VER.A\ROH
(1)
(
2
)
(
4
)
(3)
