- 41 -
LCD TV Service Manual
Hisense Confidential
8. Explode View
9. Schematic circuit diagram
HISENSE LCD19W57ACA PARTS LIST
No. Part # Part Name Qty. Code No. Remark
1 1049322 Light Window 1 RSAG8.640.062
2 1042501 Screw 2 SJ2824-87 ST3X8C Zincification
3 114175 IR Board Unit 1 RSAG2.908.1169
4 1051479 Keyboard 1 RSAG8.335.070
5 114552 Keypad 1 RSAG2.908.1168-2
6 1051906 Speaker 2 YDT37E-5W4R-F
7 1042538 Screw 4 SJ2838-87 ST4X16C.II Zincification
8 1026852 Screw 5 SJ2825-87 ST3X12C Black
9 1057324 Stand 1 WG6.121.056
10 1026924 Screw 4 SJ2824-87 ST4X16C Black
11 1031851 Screw 3 SJ2824-87 ST4X12F Black
12 1031750 Screw 4 GB/T818-2000 M4X8 Black
13 1057905 Side Label 1 RSAG8.804.842
14 1046016 Label 1 RSAG8.804.3106
15 1057771 Rating Label 1 RSAG8.807.4105
16 1056888 Bottom Label 1 RSAG8.804.3420
17 1054995 Rear Cover 1 RSAG8.074.625
Please order
them together
18 1053870 Bracket 4 RSAG8.038.1552
19 1043999 Screw 4 SJ2824-87 ST4X8F Black
20 1031172 Screw 6 SJ2832-87 ST3X10
21 1057779 Terminal Bracket 1 RSAG8.081.506 *
22 120130 Main Board 1 RSAG2.908.1544-1
23 1042512 Screw 4 SJ2836-87 M3X8 Zincification
24 117925 Power Board 1 RSAG2.908.1453
25 1042524 Screw 4 GB/T 819 M3X6 Zincification
26 1056945 Bracket Unit 1 RSAG6.150.603 *
27 1057991 LCD Panel 1 M185B1-L01
28 120249 Front Cover 1 RSAG8.074.618
31 1057774 Remote Control 1 EN-21667A
32 1048097 Power Cord 1 YS-05-E
33 1044214 LVDS Cable 1 HX-0146
NOTE: * Needn't to be stocked
