Hitachi 37HLX99 Service Manual

REPLACEMENT PARTS LIST
PRODUCT SERVICE NOTE:Components marked with a have special characteristics important to safety.Before replacing any
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don’t degrade the safety of the
receiver through improper servicing.
Capacitors: Resistors: Semiconductors:
AL: Aluminum Electrolytic CF: Carbon Film TR: Transistor
CD: Ceramic Disc CC: Carbon Composition DI: Diode
EL: Electrolitic MF: Metal Oxide ZD: Zener Diode
PF: Polyester Film VR: Variable Resistor VA: Varistor
PP: Polypropylene WW: Wire Wound TH: Termistor
PL: Plastic FR: Fuse Resistor IC: Integrated Circuit
TA: Tantalum MG: Metal Grazed
PR: Paper
TM: Trimmer
MC: Mylar
ABBREVIATIONS
104
TABLE OF CONTENTS
SYMBOL PART No. DESCRIPTION
55HDS69
55HDT79
55HDX99
SYMBOL PART No. DESCRIPTION
55HDS69
55HDT79
55HDX99
C040 AA01123R CCC105K10-B-16CT 0 0 0
SUBDIGITAL PWB C041 AA01123R CCC105K10-B-16CT 0 0 0
JP50321 0 C042 AA01123R CCC105K10-B-16CT 0 0 0
JP50322 0 C043 AA01123R CCC105K10-B-16CT 0 0 0
JP50323 0 C044 AA01123R CCC105K10-B-16CT 0 0 0
CAPACITORS C045 AA01123R CCC105K10-B-16CT 0 0 0
C001 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C046 AA01123R CCC105K10-B-16CT 0 0 0
C002 AA01343R CERAMIC CAPACITOR(0.047UF 25V- 0 0 0 C047 AA01123R CCC105K10-B-16CT 0 0 0
C003 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C048 AA01123R CCC105K10-B-16CT 0 0 0
C004 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C049 AA01123R CCC105K10-B-16CT 0 0 0
C005 AA01115R CAP.CHIP1608-B-4.7UF6.3V 0 0 0 C060 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0 0 0
C006 AA01116R CAP.CHIP1608-B-10UF 6.3V M 0 0 0 C061 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0 0 0
C007 AA01343R CERAMIC CAPACITOR(0.047UF 25V- 0 0 0 C062 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0 0 0
C008 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C063 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK 0 0 0
C009 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C078 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 0 0
C012 AA01116R CAP.CHIP1608-B-10UF 6.3V M 0 0 0 C079 0893126R CAP 1608CHIP 100PFJCH 50V TAPE 0 0 0
C014 AA01123R CCC105K10-B-16CT 0 0 0 C080 0893208R CAP 1608CHIP 1000PFKB 50V TAPE 0 0 0
C015 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C081 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 0 0
C016 AA01123R CCC105K10-B-16CT 0 0 0 C082 AA01185R CAP.CHIP-CERAMIC 22UF/16V B 32 0 0 0
C017 AA01123R CCC105K10-B-16CT 0 0 0 C083 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 0 0
C018 0893188R CERAMIC CAPACITOR(47000PF 16V) 0 0 0 C084 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 0 0
C019 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C085 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE 0 0 0
C020 AA01343R CERAMIC CAPACITOR(0.047UF 25V- 0 0 0 C086 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V 0 0 0
C021 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C087 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 0 0
C022 0893188R CERAMIC CAPACITOR(47000PF 16V) 0 0 0 C088 AA00969R CAP.CHIP2125-B-22UF6.3V 0 0 0
C023 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C089 AA00951R CERAMIC CAPACITOR(1.0UF 16V) 0 0 0
C024 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C090 AA01123R CCC105K10-B-16CT 0 0 0
C025 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C091 AA01123R CCC105K10-B-16CT 0 0 0
C026 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C092 AA01123R CCC105K10-B-16CT 0 0 0
C027 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C093 AA01113R CCC225K06-B-16CT 0 0 0
C028 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C094 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M) 0 0 0
C029 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0 C096 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 0 0
C030 AA01123R CCC105K10-B-16CT 0 0 0 C097 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 0 0
C031 AA01123R CCC105K10-B-16CT 0 0 0 C0A1 AA00969R CAP.CHIP2125-B-22UF6.3V 0 0 0
C032 AA01123R CCC105K10-B-16CT 0 0 0 C0A2 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 0 0
C033 AA01123R CCC105K10-B-16CT 0 0 0 C0A3 AA00969R CAP.CHIP2125-B-22UF6.3V 0 0 0
C034 AA01123R CCC105K10-B-16CT 0 0 0 C0A4 AA01141R CERAMIC CAPACITOR(0.1UF 16V) 0 0 0
C035 AA01123R CCC105K10-B-16CT 0 0 0 C0A5 AA01121R CERAMIC CAPACITOR(0.47UF 10V) 0 0 0
C038 AA01123R CCC105K10-B-16CT 0 0 0 C0A6 AA01121R CERAMIC CAPACITOR(0.47UF 10V) 0 0 0
C039 AA01123R CCC105K10-B-16CT 0 0 0 C0K0 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V) 0 0 0
