12
60" EXPLODED VIEW PARTS LIST
60V500A 60VX500
No PART No PART No DESCRIPTION QTY
1A NT03104 NT03106 60V500 FRAME ASSY 1
1 QD36511 QD36512 SCREEN FRAME 60V500 1
2 JT24171 JT24171 CONTROL PWB ASSY 1
3 PC05731 PC05731 POWER BUTTON V500 1
4 KQ03291 KQ03291 LED LENS V500 1
5 KR02914 KR02916 60V SCREEN ASSY 1
6 NA66782 NA66784 SCR FIX MTL H 60V500 2
7 NA66792 NA66794 SCR FIX MTL V 60V500 2
8 NJ08042 NJ08042 SP BAFFLE L V500 1
9 NJ08051 NJ08051 SP BOX COVER V500 2
10 NJ08041 NJ08041 SP BAFFLE R V500 1
11A KS06404 KS06402 60V500 MIRROR COVER ASSY 1
11 QD36521 QD36521 MIRROR COVER 60V500 1
14 NJ07822 NJ07822 MIRROR FIX PART L 50V500 1
15 NJ07821 NJ07821 MIRROR FIX PART R 50V500 1
17 MN06152 MN06152 60V500 MIRR LOW SPACER 1
18 KS06582 KS06582 1ST MIRROR 60V500 1
19 NJ07831 NJ07831 MIRROR FIX PART UP B 50V500 3
20 NJ07811 NJ07811 MIRROR FIX PART LOW 50V500 3
21 NA67801 NA67801 BACK COVER BOTTOM METAL 1
22 MN05841 MN05841 V500 BARRIER L 1
23 MN05831 MN05831 V500 BARRIER R 1
24 ME03442 ME03442 LOW UPPER COVER V500 1
25A QD36002 QD36002 60V LOW CABINET ASSY 1
25 NA68501 NA68501 BTM RAIL MTL C60 1
26 NJ08072 NJ08072 WOOFER BOX COV L V500 1
27 NJ08061 NJ08061 WOOFER BAFFLE R V500 1
28 NJ08071 NJ08071 WOOFER BOX COV R V500 1
29 NJ08062 NJ08062 WOOFER BAFFLE L V500 1
30 PH33032 PH33032 LAMP COVER 1
31 ME03592 ME03592 V500 BARRIER SIDE R 1
32 QD36153 QD36153 LOW CABINET 50V500 1
33 PH33162 PH33162 CONTROL PANEL 60V 1
34 PH33442 PH33442 V500 LO CABI COVER F60 1
35 PH33311 PH33311 FRONT TRIM 50V500 1
36 PH33301 PH33302 FRONT COVER 50V500 1
36A PH33291 PH33292 BOTTOM RAIL 60V500 1
37 PH33173 PH33174 CONTROL DOOR V500 1
38 PH33551 PH33551 FRONT SPACER BOX 60V
39 NJ08001 NJ08001 LO CABI SIDE L 60V500 1
40 NJ08002 NJ08002 LO CABI SIDE R 60V500 1
41 NA68512 NA68512 BTM SIDE FIX MTL R60 1
42 NA68511 NA68511 BTM SIDE FIX MTL L60 1
43 NA64191 NA64191 BTM RAIL MTL C60 2
44 NJ08181 NJ08181 LAMP DUCT B LC3X 1
46 NJ08171 NJ08171 LAMP DUCT A LC3X 1
47 UE22334 UE22334 60V500 OPTICAL BLOCK ASSY 1
48 NA66774 NA66774 LOW CABI METAL C V500 1
49 UE22344 UE22344 60V CHASSIS BLOCK ASSY 1
50 NA66763 NA66763 LOW CABI METAL B V500 1
51 NJ08261 NJ08261 V500 CABI BRACKET 2 2
52 NJ08271 NJ08271 V500 CABI BRACKET 3 4
53 PU00801 PU00802 ULTRAVISION BADGE 1
LC37/E/F
