50" EXPLODED VIEW PARTS LIST
50V500 50V500A 50VX500
No PART No PART No PART No DESCRIPTION QTY
1A NT03101 NT03103 NT03105 50V500 FRAME ASSY 1
1 QD36131 QD36131 QD36132 SCREEN FRAME 50V500 1
2 JT24171 JT24171 JT24171 CONTROL PWB ASSY 1
3 PC05731 PC05731 PC05731 POWER BUTTON V500 1
4 KQ03291 KQ03291 KQ03291 LED LENS V500 1
5 KR02911 KR02913 KR02915 50V SCREEN ASSY 1
6 NA66781 NA66781 NA66783 SCR FIX MTL H 50V500 2
7 NA66791 NA66791 NA66793 SCR FIX MTL V 50V500 2
8 NJ08042 NJ08042 NJ08042 SP BAFFLE L V500 1
9 NJ08051 NJ08051 NJ08051 SP BOX COVER V500 2
10 NJ08041 NJ08041 NJ08041 SP BAFFLE R V500 1
11A KS06401 KS06403 KS06401 50V500 MIRROR COVER ASSY 1
11 QD36141 QD36141 QD36141 MIRROR COVER 50V500 1
12 NJ07801 NJ07801 NJ07801 MIRROR FIX PART UP 50V500 3
14 NJ07822 NJ07822 NJ07822 MIRROR FIX PART L 50V500 1
15 NJ07821 NJ07821 NJ07821 MIRROR FIX PART R 50V500 1
16A NA69012 NA69012 NA69012 V500 MIRR SIDE MTL L 1
16 NA69011 NA69011 NA69011 V500 MIRR SIDE MTL R 1
17 MN06151 MN06151 MN06151 V500 MIRR LOW SPACER 1
18 KS06581 KS06581 KS06581 1ST MIRROR 50V500 1
19 NJ07831 NJ07831 NJ07831 MIRROR FIX PART UP B 50V500 3
20 NJ07811 NJ07811 NJ07811 MIRROR FIX PART LOW 50V500 3
21 NA64502 NA64502 NA64502 MIRR FIX LO MTL 50V 1
22 MN05841 MN05841 MN05841 V500 BARRIER L 1
23 MN05831 MN05831 MN05831 V500 BARRIER R 1
24 ME03441 ME03442 ME03442 LOW UPPER COVER V500 1
25A QD36001 QD36003 QD36005 50V LOW CABINET ASSY 1
25 NA66741 NA66741 NA66741 BTM RAIL FIX MTL C50 1
26 NJ08072 NJ08072 NJ08072 WOOFER BOX COV L V500 1
27 NJ08061 NJ08061 NJ08061 WOOFER BAFFLE R V500 1
28 NJ08071 NJ08071 NJ08071 WOOFER BOX COV R V500 1
29 NJ08062 NJ08062 NJ08062 WOOFER BAFFLE L V500 1
30 PH33033 PH33033 PH33033 LAMP COVER 50V 1
31 ME03592 ME03592 ME03592 V500 BARRIER SIDE R 1
32 QD36151 QD36153 QD36153 LOW CABINET 50V500 1
33 PH33161 PH33161 PH33161 CONTROL PANEL V500 1
34 PH33441 PH33441 PH33441 LO CABI COVER F V500 1
35 PH33041 PH33041 PH33041 FRONT TRIM 50V500 1
36 PH32981 PH32981 PH32982 FRONT COVER 50V500 1
36A PH32971 PH32971 PH32972 BOTTOM RAIL 50V500 1
37 PH33173 PH33173 PH33174 CONTROL DOOR V500 1
39 NJ07852 NJ07852 NJ07852 LO CABI SIDE L 50V500 1
40 NJ07851 NJ07851 NJ07851 LO CABI SIDE R 50V500 1
41 NA66732 NA66732 NA66732 BTM SIDE FIX MTL L50 1
42 NA66731 NA66731 NA66731 BTM SIDE FIX MTL R50 1
43 NA64181 NA64181 NA64181 BTM RAIL FIX MTL 50V500 2
44 NJ08181 NJ08181 NJ08181 LAMP DUCT B LC3X 1
46 NJ08171 NJ08171 NJ08171 LAMP DUCT A LC3X 1
47 UE22331 UE22333 UE22331 LC37 OPTICAL BLOCK ASSY 1
48 NA66774 NA66774 NA66774 LOW CABI METAL C V500 1
49 UE22341 UE22343 UE22341 LC37 CHASSIS BLOCK ASSY 1
50 NA66763 NA66763 NA66763 LOW CABI METAL B V500 1
51 NJ08261 NJ08261 NJ08261 V500 CABI BRACKET 2 2
52 NJ08271 NJ08271 NJ08271 V500 CABI BRACKET 3 4
53 PU00801 PU00801 PU00802 ULTRAVISION BADGE 1
